Apple’s new 27-inch Studio Display XDR, which boasts a 5K screen and a starting price of £2,599, is the company’s most ambitious monitor yet. Aimed squarely at professional and prosumer Mac users, it replaces the 2019 Pro Display XDR with a smaller, more affordable package that still packs a punch where it matters most: the display itself.
Screen quality
At the heart of the Studio Display XDR is a super-crisp 27-inch IPS LCD panel with a 5,120-by-2,880 resolution (218 pixels per inch). But the real star is the miniLED backlight, which uses 2,304 local dimming zones — a scaled-up version of the technology found in the MacBook Pro. This allows the display to preserve contrast by turning off backlighting where it is not needed, keeping shadows and blacks deep while delivering exceptionally bright highlights. The result is a contrast ratio of 1,000,000:1.
The brightness levels are remarkable. The screen sustains 1,000 nits for everyday content in bright environments, which already dwarfs Apple’s standard 600-nit displays. For HDR content, it reaches a peak of 2,000 nits. Independent testing has recorded a sustained SDR brightness of 572 nits and an XDR peak of 1,878 nits. This extreme brightness allows the display to overpower any bright indoor lighting and even direct sunlight, making it ideal for content creators working in varied conditions. For those who regularly deal with glare, a nano-texture coating is available as a £300 upgrade; it diffuses direct light sources very effectively.
The display is factory-calibrated for high colour accuracy, covering both the P3 and Adobe RGB colour gamuts out of the box, making it a plug-and-play option for photo and video editing. Apple also offers custom calibration and a wide variety of colour reference modes, including DICOM presets for medical imaging — essential for professional workflows such as video production, colour grading and medical imaging. For everyday use, True Tone adapts the display’s colour temperature to ambient lighting, and an auto-brightness setting is included; both can be turned off for colour-accurate work.
The adaptive 120Hz refresh rate — with Adaptive Sync that dynamically adjusts from 47Hz to 120Hz — keeps scrolling and mouse movements fluid, and the screen can automatically match frame rates to video content. However, driving the display at 120Hz requires a Mac with an M4 chip or better; Macs with M1, M1 Pro, M1 Max, M1 Ultra, M2 and M3 chips are limited to 60Hz, and Intel Macs are not officially supported. The display also works with many iPads featuring M-series chips; the iPad Pro (M5) supports 120Hz, while other compatible iPads are limited to 60Hz. The Studio Display XDR can be daisy-chained with other displays via the Thunderbolt port, and even older hardware such as the MacBook Neo can be used, though only at 4K resolution rather than native 5K.
The display is powered by the A19 Pro chip from the latest iPhone, which drives its various features. Inaudible fans keep internal components cool even in 35°C heatwaves. The screen is the best miniLED display on the market, handling blooming — the halo effect around bright objects on dark backgrounds — very well thanks to the high density of dimming zones.
Integrated features
The Studio Display XDR includes a number of features rarely found on professional monitors. It has six speakers with force-cancelling woofers that deliver 30 per cent deeper bass than the previous generation, supporting Spatial Audio with Dolby Atmos. They are infinitely better than most monitor or TV speakers and are perfectly adequate for casual listening and video watching. Three studio-quality microphones with directional beamforming handle video calls effortlessly, and the 12MP webcam supports Apple’s Centre Stage auto-panning and scanning Desk View technology, borrowed from the MacBook Pro and iPads.
The display doubles as a hub, with two Thunderbolt 5 ports (one upstream that can charge a connected laptop at up to 140W and one downstream for accessories and daisy-chaining) and two USB-C ports running at up to 10Gb/s. This allows a single-cable connection to a MacBook Pro, simplifying pro workflow setups. The A19 Pro chip also powers the camera, audio and connectivity features, though the monitor has no user-accessible operating system.
Price and target audience
The Studio Display XDR starts at £2,599 in the UK for the standard glass model with a tilt- and height-adjustable stand. The nano-texture glass version costs an additional £300, bringing the total to £2,899. Apple also offers education pricing starting at £2,909. Some retailers list the standard glass model with the tilt/height stand at £2,733.90 (special price) or £2,825.06 (regular price); the nano-texture version with the same stand is listed at £3,007.38 (special price) or £3,107.66 (regular price). A VESA mount adapter option (stand not included) is also available, with standard glass at £2,733.90 (special price) or £2,825.06 (regular price), and nano-texture glass at £2,990.11 (special price) or £2,491.76 (regular price). Notably, the stand cannot be removed after purchase unless the monitor is configured with a VESA mount at the point of purchase.
The price tag places it in prosumer and professional territory. It is £2,000 cheaper than the 2019 Apple Pro Display XDR it replaces, though the old model had a 32-inch 6K display. The standard Studio Display costs £1,499, while a direct competitor, the Asus ProArt Display PA32UCXR, is £2,799. The Studio Display XDR is not aimed at broadcast or film production reference monitors that can cost up to £30,000, but Apple has dropped the “reference monitor” language used for the Pro Display XDR, positioning this as a pro display for creative professionals. It is particularly suited to Mac-using content creators — video editors, photographers, colourists, 3D animators and game designers — who want a plug-and-play display that delivers exceptional HDR performance, high colour accuracy and integrated speakers, microphones and camera, all from a single workstation.
The display will work with some PCs that have Thunderbolt 4 or 5 and DisplayPort Alt mode, but support is not guaranteed and many features are limited, such as brightness adjustment. It cannot be used with games consoles or other devices. The monitor’s aluminium body is made with recycled materials including aluminium, copper, glass, gold, rare-earth elements, tin and zinc; it is ENERGY STAR certified and its packaging is 100 per cent fibre-based. Repair manuals are available, and no final assembly sites generate waste sent to landfill under Apple’s Zero Waste Program.
For all its brilliance, the Studio Display XDR is not without compromises. MiniLED displays cannot match the per-pixel contrast of OLED technology. The monitor lacks standard DisplayPort or HDMI inputs, relying entirely on Thunderbolt and USB-C, and it is heavy — 6.3kg without the stand, rising to 8.5kg with the tilt/height stand. It requires a modern or high-end Mac to unlock its full 120Hz capability, and the stand cannot be swapped after purchase. But for the well-heeled Mac user who demands the best screen Apple has ever made, the Studio Display XDR is a glorious super-premium display that won’t disappoint. It is, quite simply, the best miniLED screen you will see.
